006CB10100
Part No.: 006CB10100
Product Name: Coiled Air Brake Hose
Usage: Used for truck and trailer air pipeline connection, fifth wheel sliding system air circuit
Description
General Information
Part No.: 006CB10100Product Name: Coiled Air Brake HoseUsage: Used for truck and trailer air pipeline connection, fifth wheel sliding system air circuit
Material
Main body material: High strength nylonSurface treatment: Anti-aging, anti-ultraviolet, oil resistant
Size Specification
Outer diameter: 1/4 inchRetracted length: 10 inchesExtended length: 54 inchesStandard joint: 1/4 inch male thread connector
Working Parameter
Max working pressure: 150 PSIWorking temperature range: -40℃ ~ +98℃Good elasticity, automatic retraction after stretching
Performance Feature
Wear resistant, corrosion resistant, long service life
Light weight, easy installation and layout
Good cold resistance, not easy to harden in low temperature environment
Tight seal, no air leakage under stable air pressure
High flexibility, suitable for vehicle moving and shaking working condition
Installation Notice
Avoid sharp object scratching and high temperature baking
Do not exceed the rated working pressure during use
Keep away from engine heat source and exhaust pipe
Check joint tightness regularly to ensure air circuit safety
